A .223 Browning Micro Medallion A-Bolt

By Joe Berk

I recently posted a blog about a couple of accuracy loads for the 6.5 Creedmoor Browning X-Bolt. This blog focuses on a different Browning: A .223 Browning Micro Medallion A-Bolt. It’s the rifle you see here.

I bought the A-Bolt new from a local gun shop in southern California about 35 years ago. I paid $339 for it. It doesn’t have fancy walnut but when I saw it on the rack I asked to see it. I soon as I held it I wanted it. It just felt right. I fancied it as a walking around varmint rifle suitable for rabbits and coyotes, although I’ve never taken this rifle anywhere but the West End Gun Club 100-yard rifle range. I still make gun purchase decisions based on the kind of hunting and shooting I did 50 years ago in Texas. Someday I may get out and chase jack rabbits and coyotes with this rifle again. I can dream.

Browning offered their A-Bolt Medallion series, which were full-sized rifles, and their A-Bolt Micro Medallions, which have a shorter barrel and a shorter stock. The Browning Medallions and Micro Medallions were discontinued a few years ago when Browning shifted to the X-Bolt rifle, but you can still find the Micro Medallion A-Bolt rifle on the used gun racks and on the gun auction boards. A recent check showed that they go for around $650.

The rifle you see here is Browning’s Micro Medallion. I like the smaller size. It’s a lighter rifle and the shorter stock fits me well. I don’t like the gloss finish, but at the time it was all Browning offered (they later offered a satin finished rifle). What’s nice about the gloss finish, though, is that it has held up well. It and the deep bluing make this firearm look brand new. I like the rifle’s cut checkering and the darker fore end pistol grip tips, too. Browning made a big deal about their rifle’s short bolt angle in their advertising back in the 1980s and 1990s (bolt angle is the angle the bolt turns through to allow extraction, ejection, and loading). I like it, but if the rifle had a c0nventional bolt throw it wouldn’t have bothered me. It’s something different, but it’s not necessary. It is cool.

Fairly plain, gloss finished walnut. The Browning’s bolt throw is a short 60 degrees, much less than a conventional bolt action rifle’s 90 degrees. The rifle’s bluing is amazing.

A nice rifle. I use the notepad to keep track of which load I fire at which target.

Cut checkering on the Browning. These rifles were manufactured in Japan. They did a nice job.

The fore end tip and the pistol grip have rosewood caps. They look good.

Shortly after I bought the rifle, I mounted an inexpensive 4X Tasco scope on it. That worked okay for a couple of years and then the scope called it quits, so I bought another inexpensive 4X scope (a Nikko this time). The Nikko has held up well.

You might wonder: Why a nonvariable 4X scope? Why not the more popular 3-9X you see on most rifles? In my opinion, the 4X is a lot more useable in the field. I don’t get dramatically better groups with higher magnification scopes, and I like the lightness and the much larger field of view a 4X offers. Unfortunately, not too many companies offer fixed power 4X scopes these days. The scope companies’ marketing has convinced everyone they need variable scopes with high magnification.

The Nikko 4X scope was inexpensive. It has parallax and focus adjustments. Not the roll engraving on the receiver.

In my recent blog about the Browning maple Medallion 6.5 Creedmoor X-Bolt, I described a couple of accuracy loads I developed for that rifle. This time, my objectives were different. I wasn’t shooting the .223 Micro Medallion for accuracy. I was harvesting brass.

Bulk Remington .223 ammunition. It comes in a big plastic bag. I counted out 100 rounds for this range session.

A macro shot of the bulk Remington .223 ammo. Note the crimp applied to each round. I generally find that uncrimped ammo is more accurate with this cartridge. I think the crimping induces a bit of tilt in the bullet.

Several years ago I scoured the Internet looking for Remington brass. I’ve always had good luck with Remington brass (it lasts longer and it provides better accuracy, in my opinion). At that time and to my surprise, loaded Remington bulk ammo was cheaper than unprimed brass. For me it was a no brainer: I ordered a thousand rounds of loaded .223 Remington bulk ammo. When I need .223 brass, I’ll shoot up a bunch of the bulk ammo to get the brass.

The bulk Remington ammo was notoriously inaccurate in my Ruger Mini 14, which is the only rifle I had previously used with this ammunition. I wanted to see how the ammo would shoot in the Browning. I knew the Browning was accurate based on previous range testing at 100 yards (some of my reloads would shoot into a quarter of an inch in the Browning; I’ll give you those loads at the end of this blog).

The Remington ammo did well enough in the Browning. It held loads right around a minute and a half of angle at 100 yards, and it printed about where the scope was zeroed. Take a look:

Cheap ammo, but results that weren’t too shabby. I could hunt with this load.

This accuracy is good enough for minute of jackrabbit or coyote. The Browning Micro Medallion rifle is fun to shoot, too. It has negligible recoil, the shorter Micro Medallion barrel helps to keep the weight down, and it connects well at 100 yards.

About the accuracy loads I mentioned above: In a previous load development effort I tested .223 loads in several rifles, including two Remington 700 varmint guns with bull barrels and big scopes. To my surprise, the Micro Medallion and its 4X scope had no problem running with the big guns and their much heavier barrels and much higher magnifications. Here’s how the Micro Medallion and three other .223 rifles grouped a few years ago at 100 yards:

The Browning Micro Medallion shot half-inch groups with ARComp propellant (and it was basically a minute-of-angle rifle with nearly all other loads). I’ll reload the brass harvested from this range session with the Hornady V-Max bullet and ARComp propellant. This is great performance, especially considering the lightweight barrel and the 4X scope. It’s a great rifle.

Never miss an ExNotes blog:

Please click on the popup ads and visit the folks who advertise with us.

Two Browning 6.5 Creedmoor Loads

By Joe Berk

The creek is dry and getting to the West End Gun Club is a lot easier these days, so I reloaded some 6.5 Creedmoor ammo in the brass good buddy Johnnie G sent to me. I wanted to try a couple of new loads in my maple-stocked X-Bolt.

A right side view of the Browning 6.5 Creedmoor rifle. Note the muzzle brake on the end of the barrel.

I bought the X-bolt when I saw the wood, and it had a cross-country ride and a half to get to me. I saw it in a shop in Lamar, Colorado, and I knew I had to own the Browning as soon as I saw it. You don’t see many rifles with wood of this caliber.

There was a problem, though. The Colorado shop owner wouldn’t ship it to California. There’s an extra hoop or two a dealer has to jump through to ship a gun to California and I guess folks in Colorado aren’t basketball players. Here’s where capitalism came to the rescue. There’s a guy in Virginia who makes a living off of these kinds of situations, so I had the Colorado dealer ship it to the Virginia dealer, who then shipped it to my dealer in California. None of these dealers did so for free (going to Colorado-to-Virginia-to-California route wrapped the Browning in another $100 bill, and you can guess who had to pay up). But that’s okay. I wanted the rifle and now I have it. It really is an exquisite firearm. And it is exquisitely accurate. I’ll get to that in a minute.

I mounted a 4×12 Vortex scope on the Browning 6.5 Creedmoor. Check out the roll engraving on the receiver.

Another view of the 6.5 Creedmoor Vortex scope. The scope includes a parallax adjustment on the objective lens.

A macro shot of the receiver’s roll engraving. It’s a nice touch.

The stock has a darker wood fore end tip. It’s a classy rifle. The action is glass bedded from the factory.

The X-Bolt has a muzzle brake. The bluing is fine; that’s powder residue you see on it. I can feel a light puff a fraction of a second after the bullet leaves the barrel.

I used the Hornady 140-grain full metal jacket boat tail bullet for two loads I wanted to test; one with IMR 4350 propellant and the other with XBR 8208 propellant.

Reloaded 6.5 Creedmoor ammo with Winchester brass and the 140-grain jacketed hollow point boat tail bullet. It’s good looking ammo.

The business end of the 140-grain Hornady bullets.

The loads showed no signs of excess pressure after firing. The bolt opened easily and the primers were not flattened.

Winchester brass, and unflattened Winchester large rifle primers.

I full length resized the 6.5 Creedmoor brass because I have two rifles chambered in 6.5 Creedmoor (see our earlier story, A Tale of Two Creedmoors). The alternative approach is to neck size the brass only (which can theoretically offer improved accuracy), but when you neck size the brass the reloaded ammo will only fit into the rifle in which the brass was previously fired. I didn’t want to try to keep my ammo segregated by rifle, and as it turns out, I don’t need to. The full length resized 6.5 Creedmoor brass provided great 100-yard results in the Browning X-Bolt rifle with both the XBR 8208 and IMR 4350 loads.

The first shot of the day at the upper left target was low and to the left, which is a common occurrence when shooting from a clean and lightly oiled barrel. The next three grouped tightly into the orange target (I could see the bullet holes with the rifle’s 12X scope). I let the barrel cool for a few minutes, and then I fired another three rounds at the upper right target. I was pleased; the load returned an even tighter three shot group in about the same spot as the first group. Both groups, when measured later, were a satisfyingly tight half minute of angle.

I let the barrel cool again, and then I moved on to the IMR 4350 loads. Wow, talk about consistent. Both shot to the same part of the target, and both were exactly the same group size: 0.829 inches.

Two great 6.5 Creedmoor powders: IMR 4350 and XBR 8208.

My old RCBS powder trickler still works well.

I had read that IMR 4350 was a “go to” powder for 6.5 Creedmoor accuracy, and my results confirmed that. I had not found much information about XBR 8208 accuracy in this chambering, but it sure seemed to get the job done for me. As the above target shows, the XBR 8208 performed even better than the IMR 4350 loads. Here’s a bit more on info on these two loads:

- Both had the Hornady 140-grain bullets seated to an overall cartridge length of 2.800 inches.
- I did not crimp the bullets in place.
- I did not trim the brass for either load.
- The powder charges for both loads were weighed for every cartridge. I used my powder dispenser to drop a little bit lower charge, and then trickled in the last few grains.
- I used 31.5 grains of XBR 8208.
- I used 39.0 grains of IMR 4350.
- I used Winchester brass with Winchester large rifle primers.

So there you have it: Two great 6.5 Creedmoor loads for the Browning maple Medallion.

Never miss an ExNotes blog:

Don’t forget: Visit our advertisers!

A Tale of Two Hi Powers

Good buddy Robby has been a friend for 30 years. I first met Robby on a consulting gig in Georgia. He’s a fellow engineer, a firearms aficionado, a reloader, and a hell of a shot. Robby and I see each other whenever our paths cross, and more often than not the talk is about guns and reloading. Robby is a competitive pistolero and a hunter, he enjoys a finely-figured bit of walnut as much as I do, and we both appreciate the finer points of Ruger No. 1 and bolt action rifles. Robby shared with me that he recently acquired an FN Hi Power. I asked him if he would do a guest blog for ExNotes and what follows is the well-crafted result.

My grandfather: The man who taught me basically everything I know. Hunting, fishing, archery, how to shoot, how to walk through the woods silently, how to approach anything that needed fixing. Everything. He grew up during the Great Depression, he was a highly decorated recon scout during WW II, he was a cop and a security guard and he retired as a postman. I saw my grandfather as the definition of a man. He owned two handguns, one centerfire rifle (a Model 70 Winchester), a .22 and a very illegal shotgun that he sawed off because his brother split the barrel.

I own one of his handguns (a Colt Detective Special) and I have the .22 and the Model 70. The Colt Detective Special is a fine little snubby with a black paint job because someone let it rust while I was in college. I painted it and took it into my possession.

My grandfather’s Nazi war trophy with artillery sights.

My younger brother has the other handgun. It is an automatic that my grandfather took from an SS officer after dispatching him in northern Italy. It is the first automatic that I ever saw, held or fired. My grandfather kept it in the car when he delivered mail on the rural route he ran, he took it on camping trips with my brother and me, and he kept it close everywhere he went. He kept it in a holster with the German’s name written on the flap. It was a mystical gun that seemed more like Excalibur to me than some manmade object. I had all of the other firearms, so I was fine with my brother hanging on to Excalibur.

Another view of the World War II German Hi Power.

What was this mystical weapon, you ask? Just a fine Belgian copy of John Moses Browning’s “improvement” of the 1911. A 9mm Browning Hi Power, to be exact. The design was unfinished when JMB departed this mortal world, but a Belgian named Dieudonné Saive finished the design and after incorporating a few of Browning’s older patents, created the most widely-issued sidearm in history. Anyway, I am making a short story extremely long.

My brother possessed Excalibur and I needed one for myself. I bought lots of different pistols, including a couple of 1911s, and built a few custom polymer pistols with all the trimmings, but I still didn’t have a Hi Power. I was super excited when I saw Springfield and FN resurrecting the Hi Power, and I was determined to have my own.

Well, after looking for unicorn teeth in the retail shops and online, I was thinking my Hi Power was a pipe dream. The SA and the FN are made of unobtanium and the one I found online was priced accordingly. Before heading off to find The Lady of the Lake, I stopped by a local gun shop to see if I could find a 9mm AR lower. Yes, I have wide and varied tastes when it comes to things that go BANG. The owner and his minions were all tied up, so I decided to window shop a bit. I saw the Hi Power before I made it to the case. I pretended to look at everything else, hoping that no one would notice that Excalibur’s brother was RIGHT THERE in the open!

Once I got the attention of a person employed by this fine establishment, I asked to hold “that one.” “That one” had oversized, red, laminated wood grips that were apparently sized for Andre the Giant and looked much like lipstick on a large sow. I asked the owner if he knew the vintage and he replied that he thought it was a 1980s production gun. The tag affixed to the trigger guard said “consignment” and the price was $1199. That was a quick “nope” from me and I headed back to the truck with no AR lower and no Excalibur.

A week or so later, I ended up at the same shop again after dreaming up some other materials that I might need to finish the AR 9 I started. I asked to hold the Hi Power again. I noticed that it had been marked down $100 and the owner told me that it came with a spare mag and another grip. The red, behemoth handles needed to go, so I was glad to hear there was an immediate option. I still wasn’t keen on paying north of a grand, though. If it had been an actual Browning with that deep Browning bluing, that might have been much harder, but it was a well-worn FN with circus handles and non-OEM sights. It didn’t even have the “artillery” sights that my grandfather’s had. That’s what he called the adjustable-to-500-meter sights that Excalibur wore. I handed it back again and left.

My 1952 Fabrique National (FN) Hi Power with Hogue grips.

Viewed from either side, the Hi Power and its new grips look good.

A couple more weeks rocked on, I received my yearly bonus from work, I finished the AR 9, and I couldn’t get the Hi Power out of my head. We were headed that way to pick up one of my daughter’s friends and I decided to stop by and see if I could talk the guy down to $900. I walked in, eyeballed the cases and found it nestled between a couple of other pistols that I didn’t even look at long enough to identify. I asked the guy that offered to help me how much was being asked for the Hi Power this week. He yelled across the shop and asked the owner. $850 was the answer! I holstered my negotiating skills and said, “I’ll take it!”

When I made it back to the truck with it in a plastic grocery bag, I took it out and showed it to my very unimpressed better half. She said,”That is the “gun-est” looking gun I have ever seen…”

I responded, “Exactly, it is beautiful!” And off we went.

I got it home after a few hours of birthday shopping with my 15 year old, her friend and the wife and had to go straight to the yard and shoot my newest acquisition. It did not disappoint! The aftermarket sights are installed properly and are right on the target. The trigger breaks cleanly, there’s no hammer bite, and there were no failures or hiccups of any kind. Perfect…just like I hoped. Except for the furniture. I ordered a set of Hogue hardwood grips in Kingwood after a pretty thorough scouring of the internet in search of something fitting for my wooden desires.

I started my research on the serial number and completely struck out. Apparently, FN is pretty liberal and somewhat random with their numbering system, so I dug deeper. Thumb print on the right side, *S on a couple of parts, internal extractor and the five-digit serial number helped me narrow it down to a 1952 production run.

Both Hi Powers shoot well. These are 50-ft targets. My grandfather’s (and now my brother’s) Hi Power shot the group on the left; my FN Hi Power shot the group on the right.

I messaged my brother and asked him to drop Excalibur by so I could compare the two. I shot both and they are equal in all things. Except mystique. Hopefully, in time I will add a bit to mine.

Robby, that’s an awes0me story and a fine-looking pair of Hi Powers. Thanks so much for sharing it with us and our readers. You and your brother are a couple of lucky guys. Always a pleasure to hear from you, my friend, and our best to you and your family.

Help us keep the content coming: Please click on the popup ads!

More Tales of the Gun!

Stay current with our latest articles on guns, motorcycles, watches, books, movies, reloading, bicycles, construction stuff, Jeeps, philosophical ramblings, rants, and more!

A 6.5 Creedmoor Browning X-Bolt

Yeah, I’ve become a 6.5 Creedmoor believer. This is a superior cartridge and accuracy seems to just come naturally with it.

The rifle you see above is a maple-stocked Browning X-Bolt. It’s from a limited run and it sure is good looking. I bought it from a small shop in in Lamar, Colorado, when I was there on a recent secret mission. The dealer wouldn’t ship it to California so it had to go the long way around: Lamar, Colorado, to Raleigh, North Carolina, to Riverside, California, and then finally to me after I waited the obligatory 10-day cooling off period (I have to be the coolest guy in California; I’ve cooled off so many times). California has extra requirements for shipping guns to FFL holders here and the dealer in Colorado didn’t want to mess with our nutty requirements. The reshipper guy in North Carolina makes a living doing this (who says government can’t stimulate trade?). It’s crazy, but that’s our leftist Utopia here in the Golden State. I sometimes wonder if our firearms regs have ever actually prevented a crime.

Anyway, to leave the politics behind, a couple of weeks ago when I was on the range a good friend gave me a box of once-fired 6.5 Creedmoor brass another shooter had left behind. That was a sign, and I figured I’d reload it for the first range session with the new Browning.

Speer, Hornady, and Nosler 6.5mm bullets.

I already had stocked up on 6.5 Creedmoor bullets. I am probably on every reloading retailer’s email list and I get a dozen advertising emails every day. With components being in short supply nationally, if I see anything I might use I pick it up. Like the maple Browning you see above, the time to buy something that’s hard to get is when you see it (to quote Mike Wolfe).

That’s the Speer 140-grain jacketed softpoint on the left, the Hornady 140-grain jacketed boattail hollowpoint in the middle, and the Nosler 140-grain jacketed boattail hollowpoint on the right. The Nosler has a longer boattail than the Hornady, and the ogive is blunter.

From everything I’ve read and my limited experience loading for a Ruger 6.5 Creedmoor No. 1 (see my recent blog on the 6.5 Creedmoor Ruger No. 1), IMR 4350 propellant is the secret sauce for accuracy with this cartridge. I had some under the reloading bench and it got the nod for this load session.

That’s how I keep track of what I’m loading at the bench. I’ll transfer that information to a reloading label that goes on the rifle ammo container.

IMR 4350 is an extruded stick powder, and it doesn’t meter consistently through the powder dispenser. I use an RCBS trickler I’ve had for 50 years. The idea is that you drop a charge into a loading pan, it goes on the scale, and then you trickle in extra powder (a particle or two) at a time with the trickler to arrive at the exact weight.

An old and well worn RCBS powder trickler. It works well and although it sounds slow, it goes pretty quickly.

I have a set of Lee dies I use for the 6.5 Creedmoor. It’s Lee’s “ultimate” four-die set, which includes a full length resizing die and decapper, a neck-size-only die and decapper, the bullet seating die (which includes a roll crimping feature), and a factory crimp die. Lee dies are inexpensive and they work well. Their customer service is superb, too. I full length resized this batch and I didn’t crimp. I’ll experiment with that later. For this load, I just wanted to get pointed in the right direction. The refinements will come later (if they are needed).

The Lee 6.5 Creedmoor die set. Lee dies include the shell holder; most other manufacturers’ die sets do not. Lee makes good gear.

After charging the primed cases with IMR 4350, I seated the bullets. The long, heavy-for-caliber bullets and the relatively short 6.5 Creedmoor brass make for cartridges that look like hypodermic needles. It’s good looking ammo.

So how did the new 6.5 Creedmoor do? It was very cold and very windy when I went to the range. I had hoped for more pictures of the Browning in the daylight but it was so windy I didn’t want to chance the photos (I was afraid the wind would knock the rifle out of its Caldwell rest). There was only one other shooter out there; most folks were probably staying warm at home. I shot at 100 yards and the wind notwithstanding, this puppy can shoot. Here are the results from my first box of reloaded ammo…there are a few erratic groups, but they were due to me and the wind.

Here’s what the best groups looked like:

The Browning likes the 140 grain Hornady jacketed hollowpoint boattail bullets, which is good because I have a couple of boxes of those. Going up to 40.7 grains of IMR 4350 helped a bit. After I fired these rounds, I could chamber a fired case without it sticking, so I am going to load another 20 cartridges that I will neck size only.

The scope I bought for this rifle is a Vortex 4×12 (it’s made in China). This was the first time I used a Vortex. The optics are very clear. Because of the wind and the cold temperatures I didn’t try to adjust the parallax; I just set the parallax adjustment at 100 yards and shot (I’ll adjust the parallax next time, assuming the weather cooperates). The Vortex click adjustments for windage and elevation are not as tactilely distinct as they are on a Leupold or a Weaver. The clicks are squishy and I had to look at the turret graduations to keep track. Eh, it’s a $170 scope. You get what you pay for. Sometimes.

The recoil on the 6.5 Creedmore is moderate; maybe a little less than a .308. The Browning has a removable muzzle brake, and that helps.

The maple Browning (especially this one) really stands out. There were three rangemasters and one other shooter on the range the day I shot it. Everyone stopped what they were doing to look at the rifle. They thought it was a custom gun. This Browning X-Bolt is a beautiful firearm. And it shoots, too.

Never miss an ExNotes blog: Sign up here for free!

The Browning Firearms Museum

Ogden’s Finest. It was a good morning to be a Harley, I think. A little wet, maybe, but still a good day to be out and about.

You know, you could do a pretty cool adventure ride lasting a couple of weeks without ever leaving Utah. I know we’re stuck at home, self-isolating and all that, so it’s a good time to share past adventures and photos of great trips. I’ve traveled a lot, and I think Utah is one of the best destinations on the planet. It is probably the most scenic and interesting state in the country.

About that photo you see above…Susie and I rolled into Odgen one day back in 2015 to visit their museums, and these Ogden motor officers were parked out front. It was a great photo op, so I asked, they said okay, and the photo you see above is the result. It was raining that morning, but that never stopped me from riding and it didn’t stop these motor officers, either!

Ogden has four museums and an art gallery in their old railroad station, and it’s one heck of a deal. For a very minimal entrance fee, you get to see the Browning antique car collection, the Browning firearms museum, the railroad museum, the cowboy museum, and an art gallery. If you don’t have Ogden on your destinations list, maybe you need a new list!

Entering the Browning Firearms Museum. This museum alone makes Ogden a must-see destination.

Our focus in this blog is the Browning firearms museum. John Moses Browning, who did much of his work in Ogden, was perhaps the world’s most prolific arms inventor. This museum highlights his creations as well as many other interesting guns. I was in my element here!

Handguns, rifles, machine guns…Browning’s creations cover it all.

An 1886 Winchester. That buttplate is punishing with the 1886’s .45 70 cartridge.

The 1911 .45 ACP semi-auto handgun, one of Browning’s best-known inventions.

More cool Browning single-shot rifles. The second one from the top is a Browning B78. I have one of those rifles.

An ornately-engraved Browning 9mm Hi-Power handgun. It was a later design than the 1911.

The lighting in the Browning museum was dim, and that’s why the photos you see in this blog are perhaps a bit below what I try to present on the blog. I was shooting at a very high ISO without flash, as most of the displays were behind glass. The photos are not great, but they are pretty good considering the lighting.

There were a lot of interesting firearms on display, and then we migrated over to the car collection and the railroad museum. Those will be the subjects of subsequent blogs. Trust me on this…if you’re ever in Ogden, you don’t want to miss this place.

After a great lunch in downtown Ogden, we talked about where we’d go next, and Susie suggested Promontory Summit. We had learned a bit about it in the railroad museum, and we were only about 45 miles away. It’s where the railroad construction crews completed the railroad that reached across the United States. That’s coming up, so stay tuned!
